HC CARGO Aircon Compressor 241635
Full Screen

HC CARGO Aircon Compressor 241635

£200.59

Only 1 left

SKU: HCC-241635 Category: Brand:

Description

Voltage: 12
Family type: 5SEL12C
Mount. holes/front 2: 10.50
Dist. between holes 1: 80.00
Dist. between holes 2: 80.00
Dist. between holes 3: 80.00
Dist. between mount. bracket/hole 2: 92.00
Dist. between mount. bracket/hole 3: 128.00
Position: 55
Position 2: 48
Length mm: 215.00
Rotation: CW
Inlet: 20.70
Outlet: 14.40
Pulley Dist. B1: 56.50
Pulley Dist. B2: 39.00
Pulley type: SP
Pulley OD mm: 119.00
Pulley: w/
Oil type: PAG 46-H
Oil capacity: 110 ml.
Refrigerant: R1234yf
Remarks: IMPORTANT! Oil Filling. 1. Drain the oil from the compressor and measure the amount of oil. 2. Fill with the additional oil quantity and oil type as required from the vehicle manufacturer. Please be careful not to combine the different kinds of oil types.

Replaces OEM reference(s):
Peugeot: 9675657880, Peugeot: 9675659980, Peugeot: 9802456780, Peugeot: 9809274880, Valeo: C813179H, Valeo: Z0015961B, Valeo: Z0015961D, Valeo: Z00159-61G

Replaces aftermarket reference(s):
Denso: DCP21017, Mahle Letrika: ACP503000P, NRF: 320103G, Valeo: 813179
