HC CARGO Aircon Compressor Genuine OE Denso 241513

Description

Voltage: 12
Family type: 5SE12C
Mount. holes/front 2: 9.00
Dist. between holes 1: 70.00
Dist. between holes 2: 70.00
Dist. between mount. bracket/hole: 108.00
Dist. between mount. bracket/hole 2: 108.00
Position: 50
Position 2: 55
Length mm: 210.00
Rotation: CW
Inlet: 17.50
Outlet: 11.50
Pulley Dist. B1: 53.00
Pulley Dist. B2: 67.50
Pulley Grooves: 5
Pulley type: SP
Pulley OD mm: 110.00
Oil type: PAG 46
Oil capacity: 90 ml.
Refrigerant: R134a
Source: Denso
Remarks: IMPORTANT! Oil Filling. 1. Drain the oil from the compressor and measure the amount of oil. 2. Fill with the additional oil quantity and oil type as required from the vehicle manufacturer. Please be careful not to combine the different kinds of oil types.

Replaces OEM reference(s):
Denso: 447190-5040, Denso: 5se12c, Opel: 6854091, Opel: 6854102, Opel: 39006353, Opel: 39079899, Opel: 55701200, Opel: 93190812, Vauxhall se Opel: 39006353

Replaces aftermarket reference(s):
Ava (Quality Cooling): OLAK418, Delphi: TSP0155873, Denso: DCP20021, Elstock: 51-0414, FrigAir: 92030163, Hella: 8FK351114-091, Hella: 8FK351114-591, Nissens: 89100, NRF: 32588, Teamec: 8629818, Waeco: 8880100326, Waeco: 8880110645
